Quiet Floor™
This Product is no longer available, please see our Acoustik product
Impact Reduction Pad for Floors
- Economical
- Recycled “Green” Product
- Easy to Install
Product Testing & Information
- Product Specifications
- Installation Instructions
- CSI Specifications
- Flame Test
- Flame and Smoke Test
- MSDS
- MISC. Data
Product Specs
Material
100% Pre-consumer Recycled Synthetic Fiber
Features
Lightweight – Smooths Minor Floor Imperfections
Applications
Acoustic floor underlay for reducing impact floor sound in commercial and residential construction.
Thickness
1/8"
Sizes
3′×33-1/3′ & 61″×60′ Rolls
Weight
2.22 oz/sf
Density
13.3 lbs/cub. ft.
Flammability
Meets Federal Flammability Standard CPSC-FFI-70 (Pill Test)
Installation
Noise S.T.O.P.™ Acoustical Adhesive
| Quiet Floor™ – Sound Transmission Class per ASTM E-90-97 (Airborne) | |||||||
|---|---|---|---|---|---|---|---|
| 125Hz | 250Hz | 500Hz | 1KHz | 2KHz | 4KHz | STC | |
| Quiet Floor™ | 35 | 40 | 54 | 63 | 70 | 71 | 52 |
| Quiet Floor™ – Impact Insulation Class per ASTM E-492-92 (Impact) | |||||||
|---|---|---|---|---|---|---|---|
| 125Hz | 250Hz | 500Hz | 1KHz | 2KHz | 4KHz | IIC | |
| Quiet Floor™ | 58 | 56 | 44 | 30 | 20 | 18 | 58 |
